CLEARANCE K-Force TIR 55 Full Size Tow LED Light Bar (DUAL MEMORY - PREVIOUS GEN FLASH PATTERNS) SKU: X-TKFTOW55
- SAE Certification No. 201094
- RoHS Certification No. ENC171106GZ19
- U.S. Patent No. D835535, D835565, D797360
-
Eclipse Optic Technology
-
CUSTOMER SUPPORT
-
LIMITED STOCK
-
$9.99 Shipping Per Bar
Application Photos
Product videos
Videos
Specifications
Specifications
About The CLEARANCE K-Force® TIR 55 Full Size Tow LED Light Bar (DUAL MEMORY - PREVIOUS GEN FLASH PATTERNS)
This is our PREVIOUS GENERATION FLASH PATTERNS model. This unit does however have the DUAL MEMORY!
---Rear work lights come standard with activation via the Alley Button. There is not a separate on/off button for the rear work lights independently.
Optional Upgrade Descriptions:
TD/Alley/Work Light Option:
---Standard Clear = Clear in warning mode and when activated.
---Dual Color = Color ordered in warning mode / Clear when TDs and alleys and rear work lights are activated.
Features:
- PREVIOUS GEN FLASH PATTERNS
- DUAL MEMORY MODEL
- Powered by 12V
- SAE J845 Certified
- Patented LED Eclipse® Optic Technology - TIR Optics
- 104 total 3-watt MaxGen® LEDs
- 30 available flash patterns
- LED take-down and alley lights
- Rear LED Work Lights
- Built in amber arrow stick
- Upgradable multicolor traffic advisor functionality
- Arrow stick directions: right, left, center out
- Stop/Tail/Turn functionality
- Non-volatile memory recalls last flash pattern
- Lifespan of up to 100,000 hours
- Optional Supreme Control® Box sold separately
- 12' of cable from light bar to connector
- 12.5' of power cable from connector
- 12.5' of auxiliary cable from connector
- Multiple vehicle specific gutter bracket options sold separately
- Max 18.2 Amp draw
- FINAL SALE
- CLEARANCE WARRANTY*
*See Terms and Conditions
Night Mode w/ Optional Control Box (Sold Separately):
---Night Button Use = Toggle Night Mode on/off using Night Button while not hard-wiring the white cable.
---White Cable Use = Hardwire the free-standing white cable to your headlight +12VDC line to automate this feature. NOTE: This deactivates the usability of Night Button. Once hardwired, the Night button ceases to function. Make sure Night button is NOT activated before wiring white cable otherwise Night button will remain activated/illuminated.
What's included
What's included
- CLEARANCE K-Force 55 TIR Tow Light Bar
- 12' of Cable from Light Bar to Connector
- 12.5' of Power Cable from Connector
- 12.5' of Auxiliary Cable from Connector
- Adjustable Light Bar Feet Attached
- Universal Gutter Brackets (unless different mounting option is selected in drop-down)
- Supreme Control Box
- 10' Extension Cable (22 Gauge)
- 20-40' Extension Cable (16 Gauge)
- Variety of Mounting Options
