CLEARANCE MultiColor K-Force 27 Linear LED Mini Light Bar (DUAL MEMORY - PREVIOUS GEN FLASH PATTERNS) SKU: X-LKFMC27
- SAE Certification No. 201094
- RoHS Certification No. ENC171106GZ19
- U.S. Patent No. D835535, D797359
-
Eclipse Optic Technology
-
CUSTOMER SUPPORT
-
LIMITED STOCK
-
Free Shipping*
Application Photos
Product videos
Videos
Specifications
Specifications
About The CLEARANCE MultiColor K-Force® 27 Linear LED Mini Light Bar (DUAL MEMORY - PREVIOUS GEN FLASH PATTERNS)
This is our PREVIOUS GENERATION FLASH PATTERNS model. This unit does however have the DUAL MEMORY!
Alley Lights:
---Standard = Color ordered (Ex. Red/Blue bar = Red/Blue alleys)
---TIR - Clear Secondary Color = TIR Module with warning mode in primary color(s) ordered and clear in secondary color. When alleys activated, secondary color will steady burn clear. (This upgrade will always flash clear in the secondary color and always activate clear as your Alley.)
Features:
- PREVIOUS GEN FLASH PATTERNS
- DUAL MEMORY MODEL
- Powered by 12V
- SAE J845 Certified
- Patented LED Eclipse® Optic Technology - Linear Optics
- 168 Total MaxGen® Linear 3-watt LEDs
- 40 total flash patterns:
- 32 available flash patterns in MultiColor Flash Mode
- 4 flash patterns in color A mode
- 4 flash patterns in color B mode
- Non-volatile memory recalls last flash pattern
- Independent alley control functionality
- Lifespan of up to 100,000 hours
- Optional Grand Control® Box sold separately
- 12' of cable from light bar to connector
- 12.5' of auxiliary cable from connector
- 1.5' of cable from connector to cig-plug
- Weather-proof housing
- Includes Magnet brackets for mounting
- Max 11.8 Amp draw
- FINAL SALE
- CLEARANCE WARRANTY*
*See Terms and Conditions
Night Mode w/ Optional Control Box (Sold Separately):
---Night Button Use = Toggle Night Mode on/off using Night Button while not hard-wiring the white cable.
---White Cable Use = Hardwire the free-standing white cable to your headlight +12VDC line to automate this feature. NOTE: This deactivates the usability of Night Button. Once hardwired, the Night button ceases to function. Make sure Night button is NOT activated before wiring white cable otherwise Night button will remain activated/illuminated.
What's included
What's included
- CLEARANCE MultiColor K-Force 27 Linear Mini Light Bar
- 12' of Cable from Light Bar to Connector
- 12.5' of Auxiliary Cable from Connector
- 1.5' of Cable from Connector to Cig-Plug
- Magnetic Mounting Brackets
- Grand Control Box
- 10' Extension Cable
- Variety of Mounting Options
- Acari Drill-Free Roof Mount
