CLEARANCE Raptor TIR Interior Split LED Visor Light Bar (DUAL MEMORY - PREVIOUS GEN FLASH PATTERNS) SKU: X-RT10
- SAE Certification No. 180349
- RoHS Certification No. ENC171106GZ16
- U.S. Patent No. D797360
-
Eclipse Optic Technology
-
CUSTOMER SUPPORT
-
LIMITED STOCK
-
Free Shipping*
Application Photos
Product videos
Videos
Specifications
Specifications
About The CLEARANCE Raptor® TIR Interior Split LED Visor Light Bar (DUAL MEMORY - PREVIOUS GEN FLASH PATTERNS)
Optional Upgrade Descriptions:
Take Down LEDs:
---Standard Clear = Clear in warning mode and when activated.
---Dual Color = Color ordered in warning mode / Clear when TDs activated.
Features:
- PREVIOUS GEN FLASH PATTERNS
- DUAL MEMORY MODEL
- Powered by 12V
- Raptor® Series: SAE J595 Certified
- Patented LED Eclipse® Optic Technology - TIR Optics
- 40 Total MaxGen® TIR 3-Watt LEDs
- 8 MaxGen® TIR 3-Watt LED take-downs
- 26 available flash patterns
- Non-volatile memory recalls last flash pattern
- One clear Take-down module steady burn or flash in each section
- Optional Dual Color LED Take Down Module available for purchase (LED module flashes in light bar color in flash mode then changes to clear when in take down mode)
- Sleek, durable casing
- Lifespan of up to 100,000 hours
- Optional STL Grand Control® available for purchase
- Includes universal brackets
- Optional vehicle specific brackets available for purchase
- Built in windshield reflector
- Optional windshield visor extender available for purchase
- 12' of cable from light bar to connector
- 12.5' of power cable from connector
- 12.5' of auxiliary cable from connector
- 4.2 Amp draw
- FINAL SALE
- CLEARANCE WARRANTY*
*See Terms and Conditions
Night Mode w/ Optional Control Box (Sold Separately):
---Night Button Use = Toggle Night Mode on/off using Night Button while not hard-wiring the white cable.
---White Cable Use = Hardwire the free-standing white cable to your headlight +12VDC line to automate this feature. NOTE: This deactivates the usability of Night Button. Once hardwired, the Night button ceases to function. Make sure Night button is NOT activated before wiring white cable otherwise Night button will remain activated/illuminated.
What's included
What's included
- CLEARANCE Raptor TIR Visor Light Bar
- 12' of Cable from Light Bar to Connector
- 12.5' of Power Cable from Connector
- 12.5' of Auxiliary Cable from Connector
- Universal Headliner Brackets (unless different mounting option is selected in drop-down)
- Grand Control Box
- Cig-Plug vs Standard Hardwire
- 10' Extension Cable
- Vehicle Specific Headliner Brackets
- Windshield Visor Extender
