Dual Carbine® 20" Floodlight Off Road LED Light Bar SKU: W-DC20F
- RoHS Certification No. ENC171106GZ17
- U.S. Patent No. D823151
-
![image]()
5 Year Warranty*
-
![image]()
60 Day Return Policy*
-
![image]()
LIMITED STOCK
-
![image]()
Free Shipping*
Application Photos
Product videos
Videos
Specifications
Specifications
About The Dual Carbine® 20" Floodlight Off Road LED Light Bar
With intense flood optics designed for maximum light spread, the Dual Carbine® 20" LED Floodlight Off Road Light Bar from SpeedTech Lights is an extremely durable, powerful, and affordable addition to your vehicle.
Between the 40 double stacked 1.5-watt LED modules, the Dual Carbine® 20" Floodlight is able to pack a blinding 60 Watt, 7,600 Lumen output into its 20" frame. At under two feet in length, this unit provides the perfect balance of size and power for both mini and full size applications (including Ford Raptor, Gators, and Jeep).
With included cable and a pigtail connector along with L Brackets for mounting included with the bar, STL is the one stop shop for anyone looking to add a powerful LED Off Road Lightbar to the grille, roof, or bumper of their vehicle.
Between the 40 double stacked 1.5-watt LED modules, the Dual Carbine® 20" Floodlight is able to pack a blinding 60 Watt, 7,600 Lumen output into its 20" frame. At under two feet in length, this unit provides the perfect balance of size and power for both mini and full size applications (including Ford Raptor, Gators, and Jeep).
With included cable and a pigtail connector along with L Brackets for mounting included with the bar, STL is the one stop shop for anyone looking to add a powerful LED Off Road Lightbar to the grille, roof, or bumper of their vehicle.
WHAT'S INCLUDED:
- (1) Dual Carbine® 20" Floodlight Off Road LED Light Bar
- L brackets and hardware kit for mounting
- 19" of cable to pigtail connector
- Another 8.5" of cable from pigtail connector
- 10' Extension Cable
- 10 ft relay harness with On/Off switch available for purchase
- 10 ft relay harness with wireless remote and flash capability available for purchase
- Variety of Optional Mounting Brackets
- Powered by 10-28V
- (40) 1.5-watt LEDs - double stack
- 7,600 Lumens
- Flood Optics - 60-watts Intensity
- Color Temp: 6000K
- 14 Amp draw
- Weatherproof IP67 housing
- Steady burn floodlight functionality
- Floodlight beam: 90 Degrees
- Includes adjustable end cap brackets with hardware
- Includes 19" of cable to connector
- Pigtail includes another 8.5" of cable
- Optional 10 ft relay harness with On/Off switch available for purchase
- Optional 10 ft relay harness with wireless remote and flash capability available for purchase
*See Terms and Conditions
Mounting options
Literature
LIterature
Specifications
Specifications
About The Dual Carbine® 20" Floodlight Off Road LED Light Bar
With intense flood optics designed for maximum light spread, the Dual Carbine® 20" LED Floodlight Off Road Light Bar from SpeedTech Lights is an extremely durable, powerful, and affordable addition to your vehicle.
Between the 40 double stacked 1.5-watt LED modules, the Dual Carbine® 20" Floodlight is able to pack a blinding 60 Watt, 7,600 Lumen output into its 20" frame. At under two feet in length, this unit provides the perfect balance of size and power for both mini and full size applications (including Ford Raptor, Gators, and Jeep).
With included cable and a pigtail connector along with L Brackets for mounting included with the bar, STL is the one stop shop for anyone looking to add a powerful LED Off Road Lightbar to the grille, roof, or bumper of their vehicle.
Between the 40 double stacked 1.5-watt LED modules, the Dual Carbine® 20" Floodlight is able to pack a blinding 60 Watt, 7,600 Lumen output into its 20" frame. At under two feet in length, this unit provides the perfect balance of size and power for both mini and full size applications (including Ford Raptor, Gators, and Jeep).
With included cable and a pigtail connector along with L Brackets for mounting included with the bar, STL is the one stop shop for anyone looking to add a powerful LED Off Road Lightbar to the grille, roof, or bumper of their vehicle.
WHAT'S INCLUDED:
- (1) Dual Carbine® 20" Floodlight Off Road LED Light Bar
- L brackets and hardware kit for mounting
- 19" of cable to pigtail connector
- Another 8.5" of cable from pigtail connector
- 10' Extension Cable
- 10 ft relay harness with On/Off switch available for purchase
- 10 ft relay harness with wireless remote and flash capability available for purchase
- Variety of Optional Mounting Brackets
- Powered by 10-28V
- (40) 1.5-watt LEDs - double stack
- 7,600 Lumens
- Flood Optics - 60-watts Intensity
- Color Temp: 6000K
- 14 Amp draw
- Weatherproof IP67 housing
- Steady burn floodlight functionality
- Floodlight beam: 90 Degrees
- Includes adjustable end cap brackets with hardware
- Includes 19" of cable to connector
- Pigtail includes another 8.5" of cable
- Optional 10 ft relay harness with On/Off switch available for purchase
- Optional 10 ft relay harness with wireless remote and flash capability available for purchase
*See Terms and Conditions
